Features：
* Easy operate
* Optional for multiple clamping
* Suitable for a variety of worktable
* The MINI Vise can save time when changing fixtures to reduce the cost
* Clamping over hardened wedge surface by means of locking screw
Series # |
A |
B |
C |
Screw |
Clamping (KN) |
Surface Hardness (HRC) |
||
Small |
Suitable |
Big |
||||||
JG062525 |
0.984 |
0.984 |
1.02 |
0.984 |
0.47 |
1/4-28*0.63 |
18 |
48-52 |
Technical Details
| Item | OK-Vise |
| Material | Steel |
| Clamping (Kn) | 18 |
| Surface Hardness (HRC) | 48-52 |
| Usage | CNC Machine, Mechanical Processing Fastening, etc. |
| Product Dimensions | 0.6″ x 0.91″ x 0.98″ |
| Packing Dimensions | 2″ x 2″ x 1″ |
| Package | 1 |
| Certificate | ISO9001 |
| Country of Origin | Taiwan |
Additional Information
| Net Weight | 0.11 lbs |
| Gross Weight | 0.6 lbs |
